High Density Data Acquisition Modules Added

Press Release

Release Date: Feb 23 2017
Dataforth Corporation, Tucson, AZ, has just added two new modules to the powerful MAQ20 system, significantly increasing its capabilities and flexibility for a wide range of industrial applications.

The High Density Voltage Discrete Input Modules (MAQ20-DIV20 and MAQ20-DIVC20) are two versions of the same module, offering 20 discrete input channels. The MAQ20-DIV20 accepts 10-120VDC/VAC input, 24VDC nominal. The MAQ20-DIVC20 accepts 10-24VDC input, and has 24VDC compliance voltage per channel for interfacing to relay contacts, solid state switches, or other devices requiring excitation. Discrete input states can be read individually or as a block and logic polarity can be user defined as standard or inverted. Field inputs have fast switching times and pulses as narrow as 200µs can be measured. Field input connections are made through high density spring cage terminal blocks.
2017 MAQ20 Product Catalog

Input-to-bus isolation is a robust 1500Vrms in the MAQ20-DIV20/MAQ20-DIVC20 modules, and each individual channel is protected up to 150Vrms continuous overload in case of inadvertent wiring errors.

The second new module is the High Density Isolated Discrete Output Module (MAQ20-DODC20SK), which has 20 isolated discrete output channels that can switch up to 60VDC signals and sink up to 3A of current. Channels can be switched individually or in blocks, and user configurable default output states, set upon power-up or module reset, ensure failsafe operation for critical applications. Logic polarity can be user defined as standard or inverted. Field outputs have fast switching times, and field output connections are made through high density spring cage terminal blocks.

Output-to-bus isolation is a robust 1500Vrms in the MAQ20-DODC20SK module, and each individual channel is protected up to 60VDC continuous overload in case of inadvertent wiring errors. In addition, this module has 150Vrms channel-to-channel isolation, providing the ability to control equipment with or without common signal grounds or different pieces of equipment with multiple reference potentials.

In both the MAQ20-DIV20/MAQ20-DIVC20 and MAQ20-DODC20SK modules, high channel count within the narrow module package gives exceptional functionality while preserving valuable mounting space, and high density minimizes cost per channel resulting in economical monitoring and control solutions.

Two additional MAQ20 modules are in development and will be released in the near future. These are the Isolated Process Voltage & Process Current Analog Input Modules (MAQ20-ISOMV/-ISOV/-ISOI) with channel-to-channel isolation, and the Discrete Relay Output Module (MAQ20-DORLY20) with 20 channels of relay output.

Find the details on the new modules as well as updated data on all MAQ20 system modules in the 2017 MAQ20 Product Catalog.

Other MAQ20 modules include communications modules; analog input voltage, current, thermocouple, RTD and potentiometer, strain gage, and frequency modules; analog output voltage and current modules, and discrete input/output modules.

MAQ20 system advantages include:

  • Industry's most affordable price per channel
  • ±0.035% accuracy
  • 1500Vrms channel-to-bus isolation
  • Up to 240Vrms continuous field I/O protection
  • ANSI/IEEE C37.90.1 transient protection
  • Dedicated graphical control software packages
  • Advanced features including integral PID control, alarms counters, timers, and PWMs
  • 7-34VDC input power
  • -40°C to +85°C industrial operating temperature

The MAQ20 system incorporates more than 30 years of design excellence and quality in the process control industry. It was developed for factory, process, and machine automation; military and aerospace, power and energy, oil and gas, and environmental monitoring applications, and also is ideal for use in many test and measurement applications.

Worldwide, Dataforth products provide rugged signal and data integrity and wide spectrum accuracy. All products are manufactured in the USA and have been RoHS Compliant since 2006. The Dataforth Quality Management System is ISO9001:2015 registered.

For additional information, call 800-444-7644 toll-free or email sales@dataforth.com.
